Outdoor LED Screen New generation Of ultra slim and light cast aluminum cabinet

Reference prices are shown as listed in the supplier catalog on 11 Oct 2026. Currency symbols are retained as displayed. Request a current quotation; availability, exact version and compatibility are confirmed per inquiry.

Send your printer model and clear old-part photos. We confirm the correct version before quotation. Catalog entries do not confirm current stock or an approved configuration.

Product Details ⌄

New generation Of ultra slim and light cast aluminum cabinet from us

Parameter

Parameter:Value

LED encapsulation :SMD3535

Module Power:45w

Pixel Pitch :10mm

Brightness :5000 nits

Physical Density :10000pixels /㎡

Module Weight :645g

Module Resolution: 24 x 24Dots

Cabinet Weight :10.7kg

Cabinet Resolution :48 x 48Dots

Ingress Protection :IP65

Cabinet Size :W480mm x H480mm

Viewing Angle :H: 120°; V:100°

Cabinet Area: 0.2304 ㎡

Contrast Ratio :2000:1

Cabinet Material: Epoxy Paint Coated Aluminum

Brightness Control :0%-100%（Mannual/Auto/Timer brightness）

Driving Method: 1/2 Scan,Constant Current

Work Temperature: -40℃ - +60℃/10-90％RH

Storage Temperature: -30℃ - +50℃/10-90％RH

Processing Depth :14bits

Aspect Ratio: 1:1

Frame Rate: 50/60Hz

Refresh Rate:≥600Hz

Gray Scale: 8192 levels per color

Power Consumption( Max) :225w（977w/㎡）

Typical power) consumption :101w

Life Time: ≥100,000 Hours

Rigging form :Hanging/Fixed with support bracket

Input Voltage: 110-220VAC±10%

Input power frequence: 50-60Hz

Signal Connection :CAT5 Cable（L≤140m）； multimode fiber( L≤500m)； single mode fiber（L≤20km）

Input signal: RF, S-VIDEO, RGBHV, YUV, YC & COMPOSITION,etc

Super-light

Weight：10.7kg/cabinet，46kg/sqm（Note: above weight including power-supply and receiving card）

Can be installed individually

Size:480mm*480mm=0.23㎡/cabinet

Module Size：240mm*240mm

Ultra-slim

The thickest Portion：82.61mm

The thinnest Portion:14mm；

Heat Dissipation

This product can be used under ambient temperature ,which can be used outdoor.

There’re 2 layers inside the cabinet, module is installed front and power supply/receiving card are installed behind . 2 layers are separated for heat dissipation so as to prevent from interfering each other.

Cabinet is made of aluminum alloy, thermal conductivity is good.

Low electricity current design, ensure low temperature generate in screen.

Fast Installation: twist locker

There are each two groups of twist locks at horizontal and vertical direction of cabinet

Fast Installation: Cables

Each cabinet with 2 connectors, cable in and out

Maintenance：Module Front Access

it can be assembled and disassembled from front side

Maintenance：Module front access

it can be assembled and disassembled from front side

Maintenance: work individually

Single cabinet can be taken out from the assembled whole screen for maintenance.

Steps

①unplug the power cables;

②open the spanners;

③gently push the corners of cabinet and the person in front side get ready to take it.

High Precision

processed by high precision CNC machine, the size is accurate to 0.1 mm. assembly precision0.1mm.

Ingress Protection

IP65 both in front and rear of Cabinet

High and Low temperature strike test

? After Lightened up, cabinets age in Extreme Environmental Test equipment

under the temperature of -20℃ and +60℃ with 10-90％ RH for 12

hours,then proceed low temperature-high temperature strikes for 3 times,

each time lasts for 4 hours.

Structure description——cabinet appearance

Structure description——Ground bean、back support

Structure description——hanging

Effect after hanging

Installation method

Cabinets installation

Accurate locating from the pin/hole make the excellent flatness of cabinets-joint

Screen Installation—Hanging with hanging beam

Power and Signal cable connect cabinets from up to down, which make cabinets in the same line can be moved together and screen can be maintained easily

Two screen can be joint and separate without cable removed.

Operation by fine-tuning lock and adjustment

Screw to adjust the gap between die-casting Aluminum Cabinets

Screen Installation—fixed installation with ground frame

Back support jointed with screen

System

This product apply to the following system DBstar

Cable

2-in-1 connector (9 pin signal and 3 pin power)

Shield cable ( prevent interference between power and signal)

System connection diagram

Remarks:

One sending card can load 1280 x 1024 pixels

If calculated as 1 cabinet as 48×48 pixels, then one sending card can load 520 cabinets (26x20)

One lan cable can load 260cabinet

Packaging

One flight case can load 10 cabinets；

Flight case specification：P10‐1190*572*770 (mm) :141kg
